AIM-152 AAAM
Fact For 24/6/2021
FACTS
The AIM-152 AAAM was a long-range air-to-air missile developed by the United States. The program went through a protracted development stage but was never adopted by the United States Navy, due to the ending of the Cold War and the reduction in threat of its perceived primary target, Soviet supersonic bombers. Development was cancelled in 1992.
![](https://assets.zyrosite.com/cdn-cgi/image/format=auto,w=496,h=368,fit=crop/m5KjPzpGVzcqvJby/unnamed-Yg2GNjZMPBCVMDLk.jpg)
![](https://assets.zyrosite.com/cdn-cgi/image/format=auto,w=382,h=283,fit=crop/m5KjPzpGVzcqvJby/unnamed-Yg2GNjZMPBCVMDLk.jpg)
The AIM-152 originated in a U.S. Navy requirement for an advanced air-to-air missile to replace the AIM-54 Phoenix. By the mid-1980s the Phoenix was seen to be no longer cutting edge, and the Navy wanted a long range missile to counter the Soviet Tu-22M Backfire and Tu-160 Blackjack long-range supersonic bombers. The goal was to produce a weapon which was smaller and lighter than the Phoenix, with equal or better range and a flight speed of Mach 3 or more.
Some of the systems considered for the missile had already been evaluated by the China Lake Naval Weapons Center in the early 1980s as part of the Advanced Common Intercept Missile Demonstration (ACIMD) program. ACIMD missiles had been built but none had flown by the time the project was cancelled. In 1987, Hughes/Raytheon and General Dynamics/Westinghouse were selected to produce competing designs for the AIM-152.
![](https://assets.zyrosite.com/cdn-cgi/image/format=auto,w=600,h=368,fit=crop/m5KjPzpGVzcqvJby/ACIMD_missile_on_F-YD0ORlPQ2OtQnQNW.jpg)
![](https://assets.zyrosite.com/cdn-cgi/image/format=auto,w=382,h=234,fit=crop/m5KjPzpGVzcqvJby/ACIMD_missile_on_F-YD0ORlPQ2OtQnQNW.jpg)
the missile had multiple-pulse pure solid rocket motor. It also had an inertial guidance system, but midcourse updating was provided via a dual-band semi-active radar. Terminal guidance was via an electro-optical sensor, with a backup infrared seeker also included. One flaw of semi-active radar homing is that the launch aircraft must illuminate the target with its radar during flight, meaning that it must fly towards the enemy and so expose itself to greater danger. GD/Westinghouse planned to avoid this by equipping the launching aircraft with a radar pod which could illuminate the target from both forward and aft, allowing it to turn and escape whilst still providing a target for the missile.
With the fall of the Soviet Union the threat from Russian bombers effectively ended, and since no other nation could match the previous threat the AAAM was left without an enemy to defend against. The project was cancelled in 1992, shortly after the YAIM-152A designation had been given to the two prototypes.
With the phasing out of the Phoenix missile the US Navy lost its long range AAM capability, relying instead on the medium range AIM-120 AMRAAM. Longer range versions of the AMRAAM are in development to restore some of this capability.
![](https://assets.zyrosite.com/cdn-cgi/image/format=auto,w=1016,h=240,fit=crop/m5KjPzpGVzcqvJby/download-AMqrR1BQeaHGnXrG.jpg)
![](https://assets.zyrosite.com/cdn-cgi/image/format=auto,w=382,h=90,fit=crop/m5KjPzpGVzcqvJby/download-AMqrR1BQeaHGnXrG.jpg)
Source - Wikipedia
